Understanding the Architecture
The following diagram illustrates the architecture of the MSSQL Database Protector:
| Component | Description |
|---|---|
| RPAgent | A service on each node that downloads the package from the ESA over a TLS‑secured channel. |
| Log Forwarder | A service running on each node that routes audit logs and application logs to the ESA/Audit Store. |
| config.ini | A configuration file on each node that defines parameters used to control Database Protector behavior. |
| UDF Layer | A set of Database Protector user‑defined functions (UDFs) and APIs. |
| Core | A set of shared libraries that provide the core Protegrity functionality. |
